Hikmicro Habrok 4K 2.0 HH35L 384px 35mm Multi-Spectrum Binoculars

HIKMICRO HABROK 4K 2.0 HH35L 2.0

Built on the same chassis as the successful HE25L 2.0, the HH35L adds more performance in the form of a 384×288 sub-15mK NETD thermal sensor and a 35mm F1.0 thermal lens, delivering smoother detail and a significantly increased thermal detection range.

The HABROK 4K 2.0 also features HIKMICRO’s rear focus wheel and thermal/digital channel toggle, allowing fast switching between thermal and optical views while keeping the controls intuitive for one-handed use.

Key Features

• 384×288, 12μm thermal detector with NETD <15mK
• 35mm F1.0 thermal lens with detection range up to 1,800m
• 4.0×–20.0× thermal magnification
• 3840×2160 4K CMOS digital sensor
• 60mm F2.2 digital lens with 5.5×–22.0× magnification
• Up to 400m night viewing range through the digital channel
• Integrated 1,000m laser rangefinder with ±1m accuracy
• Rear focus wheel for both thermal and optical channels
• Dedicated thermal/optical rear toggle lever
• HIKMICRO Shutterless Image System (HSIS)
• Electric Image Stabilisation and Zoom Pro
• Swappable 940nm and 850nm IR illuminators
• 1920×1080 0.49-inch OLED display
• 64GB built-in storage with video, photo and audio recording
• Wi-Fi hotspot, PIP, Hot Track and digital magnetic compass
• IP67 weather protection
• Approx. 900g without batteries
• At least 6.5 hours operating time under specified test conditions

Thermal Specifications

• Sensor: VOx uncooled focal plane array
• Resolution: 384×288
• Pixel Pitch: 12μm
• Frame Rate: 50Hz
• NETD: <15mK (@25°C, F#=1.0)
• Objective: 35mm F1.0
• Detection Range: 1,800m
• Minimum Focus: 5m
• Magnification: 4.0×–20.0×
• Field of View: 13.16m × 9.87m @100m

Digital / Night Vision Specifications

• Sensor: 1/1.8″ Progressive Scan CMOS
• Resolution: 3840×2160 4K UHD
• Objective: 60mm F2.2
• Magnification: 5.5×–22.0×
• Field of View: 12.8m × 7.2m @100m
• Night Viewing Range: 400m
• IR: 940nm standard / 850nm replaceable

Laser Rangefinder

• Measuring Range: 10m–1,000m
• Accuracy: ±1m
• Laser: Class 1, 905nm

General

• Display: 0.49-inch OLED, 1920×1080
• Storage: 64GB built-in EMMC
• Protection: IP67
• Dimensions: 143.1 × 74.8 × 223.3mm
• Weight: 900g without batteries
• Operating Temperature: -30°C to +55°C
• Interpupillary Adjustment: 60–74mm
• Tripod Mount: 1/4″-20 UNC

What’s in the Box

• HIKMICRO HABROK 4K 2.0 HH35L 2.0
• Neck strap
• Type-C cable
• Tripod adapter
• 4 × rechargeable batteries
• Replaceable IR illuminator
• Quick start guide
• Lint-free cloth
• Battery charger
• Premium HIKMICRO binocular harness
